Traditional 90° Oversized Glass Clamp — Polished Chrome
A larger traditional 90° clamp, suggested for 1/2" glass where the hole has to sit farther from the edge.
Temporarily out of stock at our supplier. You can still order; it ships when restocked.
About this clamp
The CRL Traditional 90° Oversized Glass Clamp is a glass clamp for frameless glass showers; it fits 5/16" to 1/2" glass. Made by C.R. Laurence (CRL) in 4 finishes, including polished chrome, brushed nickel, matte black.
This clamp does the same job as the standard traditional 90° clamp but is bigger, so the hole can sit one and a half times the glass thickness from the edge, as tempering plants often require for 1/2" (12 mm) glass. Solid brass, for 5/16" to 1/2" (8 to 12 mm) tempered glass.
- Fits 5/16" to 1/2" (8 to 12 mm) glass
- Joins two panels at 90°
- Suggested for 1/2" (12 mm) glass
- Glass needs a hole
- Solid brass
Specs
| Finishes | 4 |
|---|---|
| Glass To Glass Angle | 90 |
| Glazing Thickness | 5/16 in. To 1/2 in. (8 mm To 12 mm) |
| Material | Brass |
| Mounting Type | Glass To Glass |
| Series | Traditional |
Complete the look in Polished Chrome
Common questions
What glass thickness does the CRL Traditional 90° Oversized Glass Clamp fit?
5/16" to 1/2" thick tempered glass. Measure your glass at a bare edge before you order; our measuring guide shows how.
How many clamps do I need?
This is one glass clamp. Most fixed panels use two or three clamps. Replace a worn clamp with the same style, size and finish so it lines up with the others.
What finishes does it come in?
Polished Chrome, Brushed Nickel, Matte Black, Polished Nickel. Match the finish of the hinges and other hardware on your shower.
Can I return it?
No. All sales are final, so please check your glass thickness, clamp style and finish before you order.
